FMB640
FMB640 is a tracking terminal with GNSS and GSM connectivity, which is able to collect device coordinates and transfer them via GSM network to a server. This device is perfectly suitable for applications, which require the location acquisition of remote objects.
Usually the FMB640 device sample is supplied to the customer in a cardboard box containing all the equipment that is necessary for operation. The package contains:
FMB640 device
4 screws for assembling device
GPS/GLONASS antenna
GSM antenna
USB cable
Port 1/2 cable
Port 3 cable
Ni-MH Rechargeable battery, 8.4V, 550 mA
Input and output power supply cable with 2x10 connection pins
PRODUCT SPECIFICATIONS
Name
Quectel EG91-EX, Quectel EG91-AUX
GNSS
GPS, GLONASS, GALILEO, BEIDOU, QZSS
Protocol compatible
NMEA, GGA, GGL, GSA, GSV, RMC, VTG
Receiver
33/99 acquisition channels
Tracking sensitivity
165 dBM
Position Accuracy
< 2.5 m CEP
Hot start
< 1 s
Warm start
< 25 s
Cold start
< 35 s
Input voltage range
10 - 30 V DC with overvoltage and reverse polarity protection
Internal Back-up battery
550 mAh Ni-Mh, 8,4 V battery
Dimension
104,1 x 76,8 x 31,5 mm (L x W x H)
Weight
197 g
RS232
2
RS485
1
CAN J1939
2
Features
Use Cases
Downloads
Videos
Features
Green/Eco Driving
Over Speeding detection
Jamming ,Idling,Towing,Crash detection
Immobilizer, iButton Read Notification
Trip detection
Odometer, Fuel counter, GNSS Unplug Detection
Offline tracking
Supported several sensor like- TPM sensor, Temperature & humidity sensor
Can read RFID Card data
Give data of ignition
Use Cases
Fleet Management:
Use Case:
The FMB640 is widely used in fleet management to track vehicles, monitor driver behavior, optimize routes, and manage fuel consumption. It helps fleet managers improve operational efficiency, reduce operating costs, and enhance overall fleet performance.
Benefits:
Real-time tracking allows for better visibility of fleet movements, leading to improved route planning and timely deliveries. Monitoring driver behavior helps identify and address unsafe driving practices, leading to reduced accidents and lower insurance premiums. Fuel consumption data helps optimize fuel usage and reduce expenses.
Logistics and Transportation:
Use Case:
The FMB640 is applied in logistics and transportation to track shipments, monitor vehicle locations, and provide real-time updates to customers. It aids in supply chain optimization and improves last-mile delivery.
Benefits:
Real-time tracking of shipments and vehicles ensures accurate ETAs, enhances customer satisfaction, and reduces the risk of theft and loss. Efficient route planning leads to reduced fuel costs and increased productivity.
Public Transportation:
Use Case:
Public transport vehicles, such as buses, use the FMB640 to provide real-time tracking to passengers, optimize routes, and improve service efficiency.
Benefits:
Passengers can access real-time information on bus locations and arrivals, leading to better public transport experiences. Optimized routes help public transport authorities improve punctuality and reduce operational costs.
